Food Grade PVC Steel Wire Hose – RUBBER&PLASTIC PVC Hose

PVC STEEL WIRE HOSE - Food Grade PVC Steel Wire Hose

FOOD GRADE PVC STEEL WIRE HOSE

Tube: Phthalate Free PVC With steel wire spiral reinforced.

Reinforcement: steel wire spiral

Applications:

Delivery of water-based foods (non-fat). For example drinks, juices, wine, vinegar, and alcoholic beverages with less than 20% alcohol.
It is used for the transportation of solid food materials and liquid transportation below 40 °C

Features:

ROHS2.0 REACH FDA Certification
Flexible, no smell
Phthalate free high quality

ADVANTAGES

suitable for food contact applications up to40°C.
FDA REACH ROHS2.0 Certification
Allows easy visual control of the fluid and identification of blockages.
The smooth inner wall reduces flow losses and enables easy cleaning.

PRODUCTS DETAILS

ECO Friendly and phthalate-free, meet the US FDA food contact safety standards
Smooth inner wall and glass clear high transport fluid efficiency。
Flexible and high pressure resistance, maintains its original shape under vacuum and high pressure.

INCH	ID	Wall	OD	W.P	Weight	Length
INCH	mm	mm	mm	Bar	kg/m	m/Roll
3/8″	10	3	16	10	0.18	100
1/2″	12	3	18	9	0.19	100
5/8″	16	3	22	9	0.26	50
3/4″	20	3.5	27	8	0.34	50
1″	25	4	33	8	0.52	50
1-1/4″	32	4	40	8	0.66	40
1-1/2″	38	4.5	47	7	0.8	40
1-3/4″	45	5	55	6	1.15	40
2″	51	5.5	62	5	1.35	40
2-1/2″	63	6	75	5	1.8	30
3″	76	6.5	89	4	2.3	30
3-1/2″	90	7	104	4	2.95	30
4″	102	7.5	117	3	3.75	10
5″	127	8	143	3	4.8	10
6″	152	9	170	2	6.5	10
